Paper Bag Forming Process
8 fully automated steps from roll stock to finished bag — all in one continuous pass.
Main Technical Parameters
| Parameter | Specification |
|---|---|
| Model | LZ-JD260 |
| Cutting Length | 120 – 400 mm |
| Bag Length (L) | 100 – 380 mm |
| Bag Width (W) | 80 – 250 mm |
| Insert Size (G) | 20 – 110 mm |
| Ladder Height | 15 – 18 mm |
| Paper Bag Speed | 100 – 600 pcs/min |
| Paper Width | 160 – 780 mm |
| Max. Paper Roll Diameter | φ1000 mm |
| Paper Core Inner Diameter | φ76 mm |
| Paper Thickness | 45 – 80 g/m² |
| Working Air Supply | ≥ 0.12 m³/min 0.5 – 0.8 MPa |
| Total Power | 380V / 3Phase 4-Wire 12 kW |
| Machine Weight | 3,500 kg |
| Machine Dimensions (L×W×H) | 6,000 × 1,600 × 1,800 mm |
Core Advantages
Key Advantages of the LZ-JD260
High-Speed Bag Production
Produces up to 400 bags per minute for continuous V-bottom paper bag production.
Integrated 4-Color Printing
Inline four-color flexographic printing supports efficient printing and bag production in one production line.
Wide Bag Size Range
Supports bag widths from 100 to 340 mm for different paper packaging applications.
Stable Web Handling
Controlled paper feeding and tension management support stable production at high operating speeds.
Precise Print Registration
Automatic registration control helps maintain accurate printing alignment during continuous production.
Efficient Production Line
Integrates printing and bag forming processes to simplify production flow and reduce separate processing steps.
