What can our equipment do?
Auto Plate Lifting, Circulating Ink System & Built-In Drying, Cut Post-Processing Time by 40% for Long-Run Production
Main Technical Parameters — Full Comparison.
Choose the right configuration for your production requirements. Both models share the same core technology platform.
| Parameter | Specification |
|---|---|
| Model | LZ-SC180M |
| Production Capacity | 160 – 200 pcs/min |
| Paper Type | Single-side PE / Double-side PE / PLA |
| Paper Weight | 190 – 320 g/m² |
| Cup Mouth Diameter (D1) | φ60 – 90 mm |
| Cup Bottom Diameter (D2) | φ45 – 65 mm |
| Cup Height (H) | 60 – 138 mm |
| Bottom Depth (h) | 5 – 12 mm |
| Control Screen | 10-inch Touch Screen |
| Cup Inspection Device | Optional |
| Power Supply | 3-Phase 380V 32 kW |
| Compressed Air | 0.6 – 0.8 MPa 0.5 m³/min |
| Cup Collection Rack (L×W×H) | 1,000 × 650 × 1,600 mm |
| Machine Weight | 4,200 kg |
| Packed Dimensions (L×W×H) | 2,800 × 1,450 × 2,000 mm |
Core Advantages
choose our paper bag machine for your production line.
Cost-Effective Servo Technology
Combines servo precision with affordable investment cost.
High-Speed Production
Output up to 200 cups per minute for efficient large-scale manufacturing.
Multi-Servo Control System
Key forming stations are servo-driven for improved accuracy and consistency.
Stable Transmission Structure
Optimized mechanical design ensures smooth operation at high speed.
Smart PLC Automation
Integrated PLC control provides easy operation and efficient production management.
Intelligent Temperature Control
Automatic temperature adjustment improves sealing quality and production efficiency.
Easy Maintenance Design
Separated transmission and forming sections allow easy cleaning and servicing.
Automatic Lubrication System
Continuous lubrication reduces wear and extends machine lifespan.
Wide Cup Size Compatibility
Suitable for producing 6–16oz hot and cold drink paper cups.
Let Linz Pack take your business to the next level right now!
It's not just about having a great machine — it's about having a trusted, seasoned supplier who helps you build your production line and grow your profits. Let Linz Pack help you win.
